FOXBORO FBMSVH
The FBMSVH module is an 8-channel analog input module for the Foxboro I/A Series MVH series Programmable Logic controllers (PLCS). It has the following characteristics:
8 analog input channels
16-bit resolution
±0.05% measurement accuracy
Supports multiple input signal types, including voltage, current, temperature, and pressure
Programmable filter
Fault indication
Product parameter
Input voltage range: -10V to +10V
Input current range: -20mA to +20mA
Sampling rate: 250μs
Filter time: 0.5ms, 1ms, 2ms, 4ms, 8ms, 16ms, 32ms, 64ms
Response time: 1ms
specification
Dimensions: 22.5mm x 90mm x 60mm
Weight: 0.1kg
