EMERSON VE3008

The EMERSON VE3008 is a high-performance, highly reliable eight-channel analog input/output module for industrial automation applications. The module provides eight analog input channels and eight analog output channels to support a variety of signal types and measurement ranges to meet the needs of various industrial control systems. The module has the following features:

High Precision measurement: The analog input channel provides high precision measurement with resolution up to 16 bits.
Wide measurement range: The analog input channel supports a wide measurement range from -20 mA to 20 mA or 0 V to 10 V.

Multiple output modes: The analog output channel supports multiple output modes, including voltage, current, and four-wire RTD.
High output accuracy: Analog output channels provide high output accuracy with resolution up to 16 bits.
Programmable gain and offset: Programmable gain and offset of analog input/output channels for flexible configuration.
Isolation protection: Provides isolation protection between analog input/output channels to prevent ground faults and noise interference.
Rugged: Rugged design to withstand harsh industrial environments, operating temperature range -40°C to +85°C.
Product parameters:

Parameter value
Number of analog input channels 8
Analog input resolution 16 bits
Analog input range -20 mA to 20 mA or 0 V to 10 V
Number of analog output channels 8
Analog output resolution 16 bits
Analog output mode voltage, current, four-wire RTD
Isolation voltage 2500Vrms
Operating temperature -40°C to +85°C
Storage temperature -55°C to +105°C
Humidity 5% to 95% RH (non-condensing)
