Product name

EMERSON LCP100 module

Product description

The EMERSON LCP100 module is the local control panel for the Emerson FIELDVUE™ DVC6200 SIS digital valve controller. It can provide the following functions:

Three buttons are provided to manually open, close or test the safety valve.
An LED indicator is provided to show the status of the safety valve.
Product parameter

Power supply voltage: 24 VDC
Current consumption: ≤ 100 mA
Dimensions: 120mm x 96mm x 76mm
Weight: 0.5kg
specification

Button:
Three buttons for manually opening, closing or testing the safety valve.
LED indicator:

An LED indicator to show the status of the safety valve.
Apply

EMERSON LCP100 modules can be used in a variety of applications, including:

Local manual control of the safety valve.
Monitor the safety valve status.
Main function

Local control:
Three buttons are provided to manually open, close or test the safety valve.
Condition monitoring:
An LED indicator is provided to show the status of the safety valve.
advantage

Easy to use: Simple design, easy to install and use.
Comparison with other similar modules

Function EMERSON LCP100 BLH Nobel 100
Number of buttons 3 1
Number of LED indicators 1 1
Power supply voltage 24 VDC 24 VDC
Current consumption ≤ 100 mA ≤ 100 mA
Dimensions 120mm x 96mm x 76mm 120mm x 96mm x 76mm
Weight 0.5 kg 0.5 kg
Overall, the EMERSON LCP100 module is very similar to the BLH Nobel 100 module in terms of functionality and parameters. Both provide three buttons and an LED indicator for local manual control and condition monitoring of the safety valve. The advantage of the EMERSON LCP100 module is that it is dedicated to the Emerson FIELDVUE™ DVC6200 SIS digital valve controller with good compatibility.
