EMERSON 1X00416H01

The EMERSON 1X00416H01 module is an analog input module for Emerson’s OVATION series DCS systems to connect analog signals to the DCS system. The module has the following features:

Supports 16 analog inputs
Supports 0-10V, 4-20mA, and 20mA anti-equal analog signals

Support for SIL 3 safety integrity level
High reliability
Easy to install and use

Product parameters:

Input type: Analog
Input signal range: 0-10V, 4-20mA, 20mA reverse phase
Resolution: 16 bits
Accuracy: ±0.1%
Operating temperature: -40°C to +70°C
Dimensions: 240 x 130 x 25 mm
Specifications:

Interface: 24VDC, DI, DO, COMM
Backplane: VME64
Power supply: 24V DC
