ELAU MAX-4/11/03/128/04/1/1/00

ELAU MAX-4/11/03/128/04/1/1/00 is a high performance, high reliability servo drive module for the control of ELAU servo motors. The module uses advanced control technology to provide precise, stable speed and torque control. The module has the following features:

High precision control: The use of advanced control technology to provide accurate motion control, accuracy up to ±0.01°.
Fast response: Fast response speed, able to quickly respond to speed instructions and load changes.

Wide speed control range: The wide speed control range enables stepless speed control from 0 rpm to rated speed.
A variety of protection functions: overload protection, undervoltage protection, overheat protection and other protection functions to ensure the safety of the motor and drive.
Easy to use: Simple to operate and easy to use.
Strong compatibility: Compatible with all kinds of ELAU servo motors.
Product parameters:

Parameter value
Rated voltage 400 VAC
Rated current 4 A
Rated power 1.5kW
Continuous torque 3 Nm
Peak torque 6 Nm
Maximum speed 3000 rpm
Control accuracy ±0.01°
Response speed <1 ms
Operating temperature -10°C to 50°C
Storage temperature -40°C to 70°C
Humidity 5% to 95% RH (non-condensing)
Protection class IP65
Dimensions 230 mm x 130 mm x 65 mm
Weight 3 kg
