BENTLY 3500/25 125800-01 Four analog input modules of the controller

BENTLY 3500/25 125800-01 Four analog input modules of the controller

BENTLY 3500/25 125800-01

Product Details:
Country of Origin: USA
Brand:BENTLY
Model: 3500/25 125800-01
Minimum order quantity :1 item
Packaging parts: raw materials for new plant and separate packaging
Delivery time :2-3 working days
Payment: Bank transfer, Western Union

Contact: Han Fangting Sales Manager
Mobile phone: 18030042035
QQ:748141623
EMAIL:748141623@qq.com
Website: www.changxindcs.com
www.changxinsz.com

BENTLY 3500/25 125800-01

Product name: BENTLY 3500/25 125800-01 module

BENTLY	3500/25 125800-01 Four analog input modules of the controller

Product Description:

The BENTLY 3500/25 125800-01 module is a 4-channel analog input module for the BENTLY 3500/25 controller. The module can be used to measure various industrial signals, such as temperature, pressure, flow, etc.

BENTLY	3500/25 125800-01 Four analog input modules of the controller1

Product parameters:

Number of inputs: 4
Input type: differential
Input voltage: 0… 10 V, 0… 5 V, ±10 V, ±5 V
Input current: ±20 mA
Input impedance: 250Ω
Resolution: 16 bits
Absolute accuracy error: +/ -0.025% full scale
Linearity error: +/- 0.005% full scale
Temperature deviation accuracy: +/- 0.001% full scale /°C
COMMON MODE REJECTION: > 70 dB 60 Hz
Insulation between each channel and bus: 1000 V AC for 60 s
Update time: 20 ms
Fault type: line break, short circuit
Mark: CE
Local signal indication: 4 leds (green) for channel Open: 4 leds (red) for channel failure:
Required bus current: 120 mA
Power consumption W: 2.4W
Specifications:

Dimensions: 102.3mm x 203.2mm x 9.5mm
Weight: 0.2kg
Operating temperature: -40°C to +70°C
Storage temperature: -40°C to +85°C
** Application Scenario:

Industrial automation
Process control
