The GE IS200TTURH1B module is a key component in the GE Mark VI turbine control system and belongs to the input terminal board. It is mainly used to receive various digital and analog signals from the turbine protection system and pass them on to the control system. These signals, which typically include parameters such as temperature, pressure, vibration, and speed, are used to monitor the operating status of the turbine and provide protection.

Figuratively speaking, this module is like the “ear” of the turbine, which constantly “listens” to the various “sounds” emitted by the tu

rbine, and then passes these “sounds” to the control system, so that the control system can understand the health of the turbine and take timely measures in case of abnormal conditions.

Main function

Signal acquisition: Collect signals from various sensors of the turbine, such as temperature sensors, pressure sensors, etc.
Signal processing: The collected signal is processed and converted into a digital signal that the control system can understand.
Signal isolation: Separate different signals to prevent mutual interference.
Protection function: When the turbine has abnormal conditions (such as excessive speed, overheating), the protection signal is triggered to protect the safety of the equipment.
Product parameters (please refer to official materials for specific parameters)
Input signal type: digital signal, analog signal
Input quantity: The value depends on the configuration
Signal range: Depending on the specific input signal
Power supply voltage: 125V DC
