Bently 125840-01

The BENTLY NEVADA 125840-01 module, also known as the High Voltage AC Power Input Module (PIM), is an integral part of the Bently Nevada 3500 monitoring and protection system. It is used to convert high-voltage AC power (175 to 264 Vac rms) to the low-voltage DC power required for 3500 systems. The module has the following features:

Reliability: Rugged design to withstand harsh environmental conditions

High efficiency: Provides high efficiency power conversion
Easy maintenance: Easy to replace
Product parameters:

Parameter value
Model number 125840-01
Input voltage 3 phase, 380-480VAC
Frequency range 50/60Hz
Power consumption depends on load and configuration
The input current varies with voltage and load
Isolation voltage 2500VAC, 60Hz, for 1 minute
Overvoltage Class III
Operating temperature -40°C to +70°C
Humidity 5% to 95% non-condensing
