BENTLY 3500/50-01-00-01

The BENTLY 3500/50-01-00-01 is a dual-channel tachometer module with versatility and the ability to monitor multiple parameters such as vibration, temperature, speed, acceleration, etc., playing a key role in industrial automation and control system applications. It can obtain the operating status of th

e device in real time, and make corresponding adjustments or issue alerts according to these states. In addition, the module is capable of receiving velocity pulse input signals from eddy current probes or magnetic probes and using these signals to drive alarm outputs. In addition to the rotational speed measurement function, it can also configure modules that provide key phase signals to other monitor modules in the frame. The key phase signal is a digital timing signal used to determine vector parameters such as frequency doubling amplitude and phase 123.

Product parameters:

Function: Dual channel, support speed monitoring, set value alarm, speed range alarm and other functions 3.
Input signal range: + 10.0V to -24.0V3.
Input impedance: Available with options such as 20 kΩ (standard), 40 kΩ (TMR), and 7.15 kΩ (internal barrier) 3
