ALLEN BRADLEY 842E-CM-MIP3BAProduct name: Allen-Bradley 842E-CM-MIP3BA Integrated motion encoder
Description: The module is a high-performance encoder from Rockwell Automation under the Allen-Bradley brand. It communicates with other automation devices (such as PLCS) via EtherNet/IP networks for accurate measurement and feedback of shaft motion parameters such as speed and position. It is widely used in various industrial automation systems requiring precise motion control.
Product parameters and specifications
Model: 842E-CM-MIP3BA

Type: Integrated motion encoder
Communication mode: EtherNet/IP
Power Supply: 10-32 VDC
Resolution: 262144 steps/revolution
Multiple laps count: 4096 laps are supported
Shaft type: 10mm solid shaft

Connector: M12 connector
Other: Supports multiple diagnostic functions, such as temperature monitoring and overload protection
Main feature
High accuracy: High resolution of 262144 steps/revolution ensures accurate position measurement.
Multi-turn counting: Supports multi-turn counting and is suitable for applications where the total number of turns of the shaft needs to be recorded.
EtherNet/IP communication: High-speed communication with PLC and other devices through EtherNet/IP.
Integrated design: The encoder and interface are integrated in one module for easy installation.
