ABB PP846

ABB PP846 is a power supply module produced by ABB, which is mainly used to provide stable DC power supply for industrial automation equipment. The module uses high-quality electronic components and advanced technology to ensure high efficiency and reliability. It has over current, over voltage and short circuit protection functions, can effectively protect the power system and load equipment. In addition, the PP846 module also has low noise, low ripple and excellent electrical performance, providing users with a stable power output.

Product parameters:

Input voltage range: 90-264V AC or DC

Output voltage: 24V DC
Output current: 20A Max
Efficiency: greater than 90%

Protection function: over current, over voltage, short circuit protection
Operating temperature: -25℃ to +55℃
Storage temperature: -40℃ to +70℃
Dimensions (W x D x H) : 170mm x 105mm x 45mm
Specifications:

Dimensions: In accordance with EN50178 standard dimensions
Weight: About 1.2kg
Installation method: rail type installation or screw fixed installation
Connection mode: Connect to the power input through the wiring terminal
