ABB PM511V08 3BSE011180R1

The ABB PM511V08 3BSE011180R1 is a high-performance, highly reliable tension control unit for controlling the tension of winding materials. The unit uses advanced tension control technology to provide accurate and stable tension control with the following features:

High precision control: The use of advanced tension control technology, to provide high precision tension control, accuracy up to ±0.1%.
Fast response: Fast response speed, able to quickly respond to load changes and speed instructions.
Wide adjustment range: Wide adjustment range allows stepless adjustment from 0 N to rated tension.

Multiple control modes: Support a variety of control modes, including tension control, speed control and position control.
Easy to use: Simple to operate and easy to use.
Strong compatibility: compatible with all kinds of winding equipment.

Product parameters:

Parameter value
Rated tension 8 kN
Maximum tension 12 kN
Measuring accuracy ±0.1%
Control accuracy ±0.5%
Response speed <1 ms
Operating temperature -10°C to 50°C
Storage temperature -40°C to 70°C
Humidity 5% to 95% RH (non-condensing)
Protection class IP65
Dimensions 230 mm x 165 mm x 65 mm
Weight 1.5kg
