ABB DI810

The ABB DI810 is a digital input module that is part of the ABB S800 I/O system. It is mainly used in industrial automation control systems to collect digital signals from various sensors or equipment and convert them into standard digital signals for PLC, DCS and other controllers to process and control.

Product description

The DI810 module has the following features:

Multi-channel digital input: provides 16 independent digital input channels, which can simultaneously collect 16 digital signals.
Input type: Mainly used for 24V DC voltage signal input.
Isolation design: The input channels are divided into two independent isolation groups, each group has 8 channels, which improves the reliability of the system.
Voltage monitoring: Each isolation group has a voltage monitoring function, which will send an a

larm signal when the voltage is abnormal.
Indicator: Each input channel has an indicator that allows users to visually view the input status.
Product parameters and specifications
Input voltage: 18V DC to 30V DC
Input current: 6mA@24V DC
Number of channels: 16
Isolation: 50V per isolation group
Operating temperature: 0℃ ~ 55℃
Mounting method: DIN rail mounting
