ABB AGDR-72C

ABB AGDR-72C module is an IGBT driver module produced by ABB. IGBT (insulated gate bipolar transistor) is a kind of power semiconductor device, which is widely used in power electronic equipment, such as frequency converter, inverter and so on. As the driving circuit of IGBT, AGDR-72C module is responsible for controlling the switching of IGBT and realizing th

e adjustment of power.

Product name resolution
ABB: ABB Group, a leading global power and automation technology group.
AGDR-72C: The specific model of the module, which represents the specific configuration and functionality of the module. The “AGDR” may stand for “Advanced Gate Drive”, or advanced gate drive.

Product characteristics
High reliability: With advanced packaging technology and materials, it has high reliability and is suitable for working in harsh industrial environments.
Fast switching: It can realize the high-speed switching of IGBT and improve the efficiency of the system.
Low power consumption: Low power consumption of the drive circuit reduces the heat generation of the system.
Protection function: With a variety of protection functions, such as over-current protection, over-voltage protection, etc., to ensure the safe operation of the system.
Product parameters (part)
Parameter Name Parameter Value (Example)
Operating voltage 15V (typical)
Output current 10A (typical)
Driving voltage ±15V (typical value)
