ABB 800PP846A product description

The ABB 800PP846A is an AC circuit breaker for 400 V voltage systems. It has 3 poles and is rated at 630 A. The circuit breaker uses ABB’s Emax 2 series technology for high reliability and durability.

Product parameter

Voltage level: 400 V
Number of poles: 3
Rated current: 630 A
Short-circuit breaking capacity: 25 kA
Release type: magnetic release
Heat release type: electromagnetic
Number of repeated operations: 200,000 times
Product specification

Size: 120 mm × 160 mm × 200 mm
Weight: 5.5kg
Product application

The ABB 800PP846A can be used in a variety of industrial applications, including:

Machine control
Process control
Building automation
Medical equipment
Traffic control
More information

Here are some additional details:

The circuit breaker has an instantaneous trip capacity of 15 kA and a short circuit breaking capacity of 25 kA.
It has an electromagnetic release and a thermal release to provide double protection.
The circuit breaker complies with IEC 60947-2.
The ABB 800PP846A is a high-performance AC circuit breaker that can be used in a variety of industrial applications. It features robust protection, industry-standard design and reliability.

Here’s how the ABB 800PP846A compares to the GE IS220PSVOH1A:

Features ABB 800PP846A GE IS220PSVOH1A
Voltage class 400 V 400 V
Number of poles 3 Poles 3 poles
Rated current 630 A 250 A
Short-circuit breaking capacity 25 kA 12 kA
Trip device Type Magnetic trip device + thermal trip device Magnetic trip device + thermal trip device
Number of repeated operations 200,000 times 200,000 times
Dimensions 120 mm x 160 mm x 200 mm 77.5 mm x 100 mm x 145 mm
Weight 5.5 kg 2.5 kg
The ABB 800PP846A has a higher current rating and short-circuit breaking capability for higher power applications. The GE IS220PSVOH1A has a smaller size and weight for applications where space is limited.
