ABB 5SHX1960L0006

The ABB 5SHX1960L0006 module is a high-performance IGCT (insulated gate turn-off thyristor) module that belongs to ABB’s family of power electronics. IGCT is a power semiconductor device that combines the high current drive capability of thyristors with the high input impedance of MOSFETs. The module is designed for high-voltage and high-current applications, and is often used in industrial automation, power electronics, new energy and other fields, mainly for high-power switching and frequency conversion control.

Product name resolution

5SHX1960L0006 is the internal part number of ABB, which contains information about the product structure, performance, manufacture date, etc.
Product description
The core component of the module is the IGCT chip, which can switch high voltage and high current quickly, and has a low on-off voltage drop, so as to achieve efficient power conversion. The package form of the module is usually a die package, which has good heat dissipation performance and mechanical strength.

High voltage and high current: Designed for high voltage and high current applications, suitable for harsh working conditions.
Fast switching: Fast switching speed for high frequency applications.
Low on-voltage drop: Reduces power loss and improves efficiency.
High reliability: The use of advanced packaging technology, with good reliability.
Product parameters and specifications (please refer to ABB’s official data manual for specific parameters)
IGCT type: Usually high voltage and high current type. For details, see the data manual.
Package: die package
Operating temperature: -40℃ to +150℃
Rated current: Depending on the specific model, usually several hundred amps to several thousand amps.
Rated voltage: Depending on the specific model, usually several thousand volts.
Product application
Industrial automation: high voltage inverter, large motor drive, etc.
Power electronics: High voltage direct current transmission (HVDC), static reactive power compensation (SVC), etc.
New energy: HVDC distribution, offshore wind power converters, etc.
