ABB 5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152

ABB 5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152 module is an IGCT module produced by ABB company, belonging to the 5SXT series, using IGCT (integrated gate commutated thyristor) technology. It has the characteristics of high voltage, high current, fast s

witching, etc., and is suitable for various medium and high voltage power electronics applications, such as frequency converter, DC transmission, wind power, photovoltaic and so on.

Product parameters:

Model: 5SHX1445H0001 3BHL000391P0101 3BHB003230R0101 5SXE05-0152
Rated voltage: 4500V
Rated current: 1445A
Maximum switching frequency: 12kHz
Cost:
Switching loss: 2.5J
On-off loss: 2.0V
Cooling method: water cooling
Weight: About 30kg
Specifications:

Size:
Length: 300mm
Width: 170mm
Height: 100mm
Connection mode: bolted connection
