ABB 3BHB004661R0101

The ABB 3BHB004661R0101 module, whose product model is KUC711AE101, is a Gate Unit Power Supply (GUSP) designed for ABB power electronic equipment such as frequency converters. It is mainly used to provide driving power for IGBT and other power semiconductor devices to ensure the reliable operation of the devices.

Main function

Drive power supply: Provide stable gate drive voltage and current for power devices such as IGBTs.
Protection function: Provides over current, over voltage, short circuit and other protection functions to ensure the safe operation of the system.
Signal isolation: Realize the isolation between the control circuit and the power circuit to improve the reliability of the system.
Product parameters and specifications (typical values, please refer to the product data manual)
Model: KUC711AE101
Order number: 3BHB004661R0101

Input voltage: depends on the specific model and application
Output voltage/current: depends on model and application
Operating temperature: -25℃ ~ +70℃
Size: Depends on specific model and package
Product characteristics
High reliability: Industrial grade design, suitable for harsh industrial environments.
High efficiency: High conversion efficiency, reduce energy loss.
Modular design: easy installation and maintenance.
