ABB 216VC62A

The ABB 216VC62A module is a 32-channel digital input module produced by ABB for the Advant OCS series control system, which is used to convert the switching signal into a digital signal for the control system to process. The module has the following features:

32 channels digital input
Supports both NPN and PNP input types
Input voltage: 24VDC

Filtering time: 1ms

Indicators: Module status indicator and channel status indicator
Product parameters:

Model: 216VC62A
Type: Digital input module
Number of channels: 32
Input type: NPN/PNP
Input voltage: 24VDC
Filtering time: 1ms
Indicators: Module status indicator and channel status indicator
Power supply: 24VDC
Power consumption: 4W
Operating temperature: 0℃~60℃
Storage temperature: -40℃~85℃
Relative humidity: 5%~95% (no condensation)
Protection level: IP20
Installation method: guide rail installation
