ABB UNITROL1010

ABB UNITROL 1010 module is an exciting control module produced by ABB and belongs to its UNITROL family of products. The module adopts advanced digital control technology, which can precisely control the excitation system of various generators and motors.

Product parameter

Input voltage:
Ac: 100Vac-240Vac
Direct current: 110VD-300VDC

Output voltage:
Ac: 0-100Vac
Direct current: 0-300Vdc
Output current:
Continuous: 10A
Peak value: 20A
Power: 1000VA
Frequency range: 50Hz-60Hz
Control mode:
Voltage control
Current control
Power control
specification

Dimensions: 176mm x 114mm x 25mm
Weight: 0.5kg
Ambient temperature: -20°C – 70°C
Humidity: 5%-95% (non-condensing)
Apply

Generator excitation
Motor excitation
Process control
Electric power system
