ABB 3ASC25H214 DATX130

The Chinese name of ABB 3ASC25H214 DATX130 module is DATX130 Redundant Rotary feedback Board. It is a module in the ABB AbilityTM System 800xA Safety Instrumentation System (SIS) to capture rotational speed and position information of rotary machinery and convert it into signals that can be recognized by the controller. It has high reliability and security and can be used in a variety of safety-critical applications.

Product description
The features of this module include:

3-channel redundancy design ensures system security and reliability
Supports a variety of speed and position sensors

High diagnostic coverage allows early detection of faults
Meets IEC 61508 SIL 2/3 safety level requirements
Product parameter
Parameter value
Module type Redundant rotary feedback board
Supports sensor types such as speed sensor and position sensor
The input signal range can be configured as required
Accuracy ±0.1%
Resolution 16 bit
Response time ≤250 ms
Power supply voltage 24 VDC
Power consumption 2 W
Operating temperature range -40°C to +70°C
Storage temperature range -55°C to +85°C
Relative humidity 5% to 95% (non-condensing)
Vibration resistance 2 g (10 Hz to 500 Hz)
Impact resistance 10 g (11 ms)
Dimensions 146 mm x 110 mm x 40 mm
Weight 1 kg
Protection class IP65
