AB 20-HIM-A6

Allen-Bradley 20-HIM-A6 is an enhanced Human Machine interface module (HIM) designed for PowerFlex 7 Series drives. It provides an intuitive user interface for configuring, monitoring, and diagnosing PowerFlex drives and their connected peripherals. With an all-digital LCD display, the module is easy to operate and suitable for various industrial environments.

Product parameters and specifications:

Model: 20-HIM-A6

Type: Human-Machine Interface Module (HIM)
Scope of application: PowerFlex 7 series inverter
Display: Full digital LCD
Protection level: NEMA Type 1
Installation mode: Handheld or mounted on a drive
Communication interface: Dedicated interface to connect PowerFlex drive
Functions: Parameter configuration, status monitoring, fault diagnosis, and data recording
Main functions:
Parameter configuration: Set various parameters of the driver, such as motor parameters, control mode, PID parameters, etc.
Status monitoring: real-time display of the driver’s operating status, output frequency, current, etc.
Fault diagnosis: Displays fault codes to help users quickly locate and resolve problems.
Data logging: Record the operating data of the drive for easy analysis and troubleshooting.
Application scenario:
Motor control system: Used to configure and monitor PowerFlex drives for precise control of motors.
Automated production line: used to control and monitor the motors on the production line.
Various industrial applications: Suitable for local operation and monitoring of frequency converters.
