AB 1769-ECR

The AB 1769-ECR module is part of Rockwell Automation’s CompactLogix family of products and is primarily used to extend the communication network of CompactLogix controllers. As the end point of the network, it plays the role of stabilizing the network signal and preventing the signal reflection. In addition, the module also provides additional power and grounding to ensure the stable operation of

 the entire system.

Main function
Network termination: Terminates the CompactLogix controller communication network to prevent signal reflection.
Power supply and grounding: Provides additional power supply and grounding to ensure system stability.
Extension interface: In some cases, additional interfaces can be provided for connecting other devices.
Product parameters and specifications

Type: CompactLogix Side panel module
Functions: Network termination, power supply and grounding
Installation: Installed on the right side of the CompactLogix controller
Size: Varies by model and controller
Working environment: Industrial environment
Application field
Industrial automation: Widely used in various industrial automation systems, as an auxiliary module of CompactLogix controller.
Process control: Used in process control systems to provide a reliable network connection.
peculiarity
Easy installation: Compact design and easy installation.
High reliability: Industrial grade design, suitable for harsh industrial environment.
Good compatibility: Fully compatible with CompactLogix series products.
