AB 1746-INT4

The AB 1746-INT4 is an isolated thermocouple/millivolt analog input module for the SLC 500 series of programmable logic controllers (PLCS) from Rockwell Automation. It supports four analog input channels to receive data from thermal couplers or other millivolt sensors.

Product parameter
Input type: thermal chance or millivolt analog signal
Supported thermocouple types: J, K, T, E, C, R, S, B, and N
Input range: Depends on the specific thermocouple type

Resolution: 12 bits
Accuracy: ±0.1% full scale
Isolation: Input and output are isolated
specification
Dimensions: 35.6mm x 89mm x 25.4mm (1.40″ x 3.50″ x 1.00″)

Mounting method: DIN rail mounting
Certification: UL, CUL, CE, CB, CCC
Apply
The AB 1746-INT4 module can be used in the following applications:

Measure temperature
Measuring pressure
Measured flow
