A-B 2711-T5A8L1

Product name: A-B 2711-T5A8L1 module

Description: A-B 2711-T5A8L1 module is an analog input/output module manufactured by A-B for industrial control systems. It has four analog input channels and four analog output channels, each of which can measure or output analog signals from 0 to 10 V.

Product parameters:

Number of channels: eight (four analog inputs, four analog outputs)
Measurement range for each channel: 0 to 10 V
Power Supply: 24 V DC
Dimensions: 72 x 96 mm
Specifications:

Operating temperature: -40 ℃ to 70 ℃
Storage temperature: -40 ℃ to 85 ℃
Relative humidity: 5% to 95% (no condensation)
Vibration: 20 G rms, 10-50 Hz
Impact: 50 G, 11 ms
Applications:

The A-B 2711-T5A8L1 module can be used in A variety of industrial applications, including:

Process control: Used to measure and control temperature, pressure, flow and other process variables.
Mechanical control: Used to measure and control position, speed, acceleration and other mechanical variables.
Data acquisition: Used to collect and store various analog signals.
Specific functions:

Four analog input channels: Can be used to measure a variety of analog signals.
Four analog output channels: can be used to generate a variety of analog signals.
High accuracy: The module has an accuracy of up to 0.05%.
The A-B 2711-T5A8L1 module is A powerful module that can be used in a variety of industrial applications.

Specific function description:

Analog input channels: Each analog input channel can measure analog signals from 0 to 10 V.
A picture of the simulated input channel opens in a new window
www.taobao.com
Analog input channel
Analog output channel: Each analog output channel can output analog signals from 0 to 10 V.
A picture of the simulated output channel
