A-B 2711-K6C15X

The A-B 2711-K6C15X module is A 16-channel analog input module manufactured by Rockwell Automation for the CompactLogix 5000 series PLC, which is used to convert analog signals to digital signals for PLC processing. The module has the following features:

16 channels analog input

Both voltage and current input types are supported
Input range: ±10V, ±20V, ±50V, 0-10V, 0-20V, 4-20mA

Resolution: 16 bits
Sampling rate: 1kHz
Product parameters:

Model: 2711-K6C15X
Type: Analog input module
Number of channels: 16
Input type: Voltage/current
Input range: ±10V, ±20V, ±50V, 0-10V, 0-20V, 4-20mA
Resolution: 16 bits
Sampling rate: 1kHz
Indicators: Module status indicator and channel status indicator
Size: 89mm x 64mm x 25mm
Weight: 0.25kg
Product Specifications:

Power supply: 24VDC
Power consumption: 4W
Operating temperature: 0℃~60℃
Storage temperature: -40℃~85℃
Relative humidity: 5%~95% (no condensation)
Protection level: IP20
Installation method: guide rail installation
Isolation voltage: 2500Vrms
