A-B 2094-BC02-M02-S

The A-B 2094-BBC02-M02-S module is A 2-channel pulse encoder input module from Rockwell Automation for Kinetix 6000 series servo systems. The module can receive the pulse signal from the pulse encoder for controlling the motion of the servo motor.

Product parameter
Number of channels: 2
Input type: pulse encoder
Resolution: 1024, 2048, 4096, 8192

Counting speed: 1MHz
Filter time: 0.5ms, 1ms, 2ms, 4ms, 8ms, 16ms
Dimensions: 120 x 70 x 80 mm
Weight: 0.3kg
specification

passage

Quantity: 2
Type: Pulse encoder
Resolution: 1024, 2048, 4096, 8192
count

Counting speed: 1MHz
Filter time: 0.5ms, 1ms, 2ms, 4ms, 8ms, 16ms
Power source

Voltage: 24V DC
Power consumption: 10W
environment

Operating temperature: -20°C to 70°C
Storage temperature: -40°C to 85°C
