A-B 1794-TB3T Flex I/O system - Changxin Automation

A-B 1794-TB3T Flex I/O system

Product Categories

Hot Products

A-B 1794-TB3T Flex I/O system

A-B 1794-TB3T

Today’s recommended products:
NVIDIA H100 PCIE
NVIDIA H800 PCIE
LAM 839-101612-885
LAM 839-101612-887
LAM 719-101612-885
LAM 719-101612-887
Many in stock, first come first served, first-hand source, channel
Contact: Han Fangting Sales Manager
Mobile :18030042035
QQ: 748141623
Email: 748141623@qq.com
Web site :www.changxindcs.com
www.changxinsz.com

We operate ABB, GE aereration, A-B, Honeywell, KUKA, SCHNEIDER, Bentley, TRICONEX Invensys, WOODWARD, FOXBORO, WESTINGHOUSE, and MOTOROLA MOTOROLA, KEBA, KOLLMORGEN, EMERSON, HIMA dark horse, industrial and commercial energy storage, container energy storage, household light energy storage, (peak cutting, valley filling, backup power supply) can be contacted if necessary.

Country of Origin: USA
Moq :1 piece
Packaging: new raw materials and individual packaging
Delivery time :2-3 working days
Payment method: Bank transfer, Western Union

A-B 1794-TB3T

The Allen-Bradley 1794-TB3T module is a dedicated terminal substrate in Rockwell Automation’s Flex I/O system. It is mainly used to connect and configure various types of temperature sensor modules, such as thermocouples, thermal resistors, etc. The module provides special terminals to facilitate the installation and wiring of the temperature module, and provides the necessary power supply and signal transmission path for the temperature module.

Product parameters and specifications:

A-B 1794-TB3T Flex I/O system
Model: 1794-TB3T
Type: Flex I/O Temperature module terminal base board
Voltage class: 125V AC/DC
Maximum current: 10A
Wire gauge: 0.21 x 1.3 mm² (24-16 AWG) stranded wire

A-B 1794-TB3T Flex I/O system1
Insulation: Basic insulation, providing 125V (continuous) voltage isolation
Terminal screw torque: 0.56-0.79 Nm (5-7 lb-in)
Special features: With cold compensating terminal
Main functions:
Connecting temperature modules: Special terminals are provided to facilitate the connection of various types of temperature sensor modules.
Supply power: Supply power to the connected temperature module.
Cold end compensation: Provides cold end compensation terminal for improving measurement accuracy.
Signal transmission: Transmit the temperature signal to the PLC.
