The AB 1766-L32BXBA module is a 32-point analog input module for the Allen-Bradley MicroLogix 1400 control system. The module supports a variety of voltage or current input signals from 0 to 10 V, -10 to 10 V, 0 to 20 mA, and -20 to 20 mA.

Product parameters:

Number of analog input channels: 32
Input signal types: 0 to 10 V, -10 to 10 V, 0 to 20 mA, -20 to 20 mA
Input signal range: 0 to 10 V: 0 to 10 V, -10 to 10 V: -10 to 10 V, 0 to 20 mA: 0 to 20 mA, -20 to 20 mA: -20 to 20 mA
Resolution: 16 bits
Accuracy: 0.001V
Power supply voltage: 24 V DC
Operating temperature: -25 to 70 degrees Celsius
Protection level: IP67
Specifications:

Dimensions: 120 x 70 x 25 mm
Weight: 100 g
Application field:

The AB 1766-L32BXBA module is widely used in various industrial automation systems, such as process control systems, robot control systems, SCADA systems, etc. It can be used to measure various physical quantities, such as temperature, pressure, flow rate, speed, etc.

Note:

AB 1766-L32BXBA module is an industrial grade product, should pay attention to the following matters when using:

When using, attention should be paid to the limitation of voltage and current to prevent overvoltage or overcurrent from damaging the module.
When using, pay attention to the protection level to prevent water or dust into the module.
Pay attention to maintenance during use to prevent module damage.
