A-B 1756-DNB/D
Allen-Bradley 1756-DNB/D is a bridge module that connects the ControlLogix system to the DeviceNet network. It acts as an intermediary between the two networks, allowing ControlLogix PLC to communicate with various devices on DeviceNet, such as servo drives, smart sensors, I/O modules, etc.
Main function
DeviceNet Network Scan: Discover and identify devices connected to DeviceNet.
Data transfer: Transfer data between ControlLogix and DeviceNet for information exchange.
Network Management: Manages the topology and configuration of the DeviceNet network.
Product characteristics
Flexible communication: Supports multiple DeviceNet communication rates.
High reliability: Ensure the reliability and real-time data transmission.
Easy configuration: Configuration via Rockwell Automation’s programming software.
Strong compatibility: can be used with a variety of ControlLogix controllers.
Product Specifications (part)
Communication rate: 125kbps, 250kbps, 500kbps
Number of nodes: Multiple DeviceNet devices can be connected
Power Supply: From the ControlLogix backplane
