A-B 1394-AM04

The Allen-Bradley 1394-AM04 axis module is part of the 1394 digital AC multi-axis motion control system. The module is A series A /B series module, with 530/680 V DC input voltage, can output 310 V AC /390 V AC, 3 phases, continuous output current of 4.5 amps, peak current of 9 amps, The continuous output power is 2.4 kW (310 V AC) and 3 kW (390 V AC).

The module has the following features:

High performance: The module has a high performance processor and high speed servo driver to achieve high precision and high speed motion control.
Flexible configuration: The module can be configured into up to 4 shaft module

s, each connected to a motor.
Easy to use: The module is easy to configure and use, with intuitive programming software and clear status indicators.
Product parameters:

Part number: 1394-AM04

Voltage: 4.8 amps 1 phase 530/680 VDC
Power: 2.4 kW (310 V AC) or 3 kW (390 V AC)
Continuous output current: 4.5 amps
Peak output current: 9 amps
Speed range: 0 to 6000 rpm
Acceleration: 1000 rad/s²
Positioning accuracy: ±0.001 degrees
Product Specifications:

Dimensions: 12.19 inches (310 mm) x 9.81 inches (249 mm) x 4.33 inches (110 mm)
Weight: 9.81 pounds (4.45 kg)
