9566-810 TRICONEX

The TRICONEX 9566-810 Digital Output Terminal Board is a highly reliable, high-performance digital output module for the Triconex Trident Safety Instrumentation System (SIS). It provides 32 relay output channels for controlling the status of various field devices. The 9566-810 is suitable for a variety of security applications that require high reliability and redundancy, such as:

Oil and gas
chemicals
electricity
Nuclear industry
transportation
Product parameters:

Number of channels: 32
Output type: Relay output
Rated voltage: 24 V DC or 48 V DC
Rated current: 2 A
Response time: < 2 ms

Power consumption: < 5 W
Operating temperature: -40°C to +70°C
Protection level: IP67
Specifications:

Dimensions: 115 mm x 60 mm x 23 mm
Weight: About 200 g
Material: Aluminum alloy
Connection: Eurocard plug
Applications:

Emergency shutdown system
Valve control
Pumping station control
Relay control
Signal indication
