1756-ENBT AB
The AB 1756-ENBT is an Ethernet/IP communication module that provides a network connection for Allen-Bradley ControlLogix controllers. The module has the following technical specifications:
- Communication Ports: 1 RJ45 10/100 Mbps Ethernet Port
- Power Requirements: 5V DC, 500mA
- Operating Temperature: 0-60°C (32-140°F)
- Dimensions (H x W x D): 4.13 in x 1.77 in x 5.32 in (105 mm x 45 mm x 135 mm)
- Weight: 0.2 kg (0.44 lbs)
The parameters for the AB 1756-ENBT module can be configured using the Studio 5000 Logix Designer software. The following parameters can be configured:
- IP Address
- Subnet Mask
- Default Gateway
- DNS Server
- Hostname
Additionally, the module supports Quality of Service (QoS) configuration for prioritizing network traffic. It also supports the Device Level Ring (DLR) protocol for resilient network topologies.
The AB 1756-ENBT is an EtherNet/IP communication module manufactured by Allen-Bradley. It is a communication module that is designed to enable ControlLogix processors to connect to an EtherNet/IP network. The module provides a reliable and secure communication link between controllers, devices and the enterprise network.
The AB 1756-ENBT module has a built-in switch that allows it to support daisy-chaining of devices, which helps reduce the number of switches required in a system. It also supports multiple connections, providing redundancy and increased availability.
This module has a data rate of 10/100 Mbps, which is sufficient for most industrial applications. It supports both half-duplex and full-duplex communication modes, allowing it to operate in a wide range of environments.
In addition, the AB 1756-ENBT module has a user-friendly web interface that allows for easy configuration and monitoring of the module. It also has diagnostic features that enable easy troubleshooting and fault-finding.
Overall, the AB 1756-ENBT is a reliable and efficient communication module that is well-suited for industrial applications that require EtherNet/IP connectivity.
