3500/22M 138607-01

The Bently Nevada 3500/22M 138607-01 module is a transient data interface module from Baker Hughes (formerly GE Oil & Gas) under the Bently Nevada brand for use in the 3500 Series monitoring systems. As the interface between the system and compatible software, it is responsible for collecting, processing and transmitting monitoring data, providing critical information for equipment health monitoring and fault diagnosis.

Product name resolution

Bently Nevada: a product brand focused on rotating machinery monitoring and protection.
3500/22M: Product series and models, part of the 3500 series monitoring system.
138607-01: Product specific identification code, used to distinguish different models.
Product description
The 3500/22M module is an important part of the 3500 monitoring system, which combines the functions of the rack interface module (RIM) with those of the communication processor. The module supports proprietary protocols for configuring racks and retrieving mechanical information. At the same time, it also has the ability of data acquisition, and can transmit the collected data to the upper computer software for analysis and processing.

Features: Rack Interface Module (RIM) and communication processor
Protocols: Supports proprietary protocols for configuring racks and retrieving mechanical information
Data acquisition: can collect vibration, temperature, pressure and other data
Communication interface: Supports communication with host software
Installation: Installed on the rack of the 3500 monitoring system
