1794-TBNF AB
The 1794-TBNF AB is a ControlNet Flex I/O module manufactured by Allen-Bradley. It has a voltage rating of 24V DC and is designed to be used with a ControlNet network. The module has 8 inputs and 8 outputs, each of which are isolated.
The module has a compact design, allowing it to be easily mounted on a DIN rail. It also features an LED indicator for each input and output, which provides a visual indication of the status of each point.
In addition, the 1794-TBNF AB has a built-in diagnostic feature that provides information on the module’s status, including the status of each point. This information can be accessed remotely via a ControlNet network.
Overall, the 1794-TBNF AB is a reliable and efficient ControlNet Flex I/O module that is ideal for use in a variety of industrial applications.
The 1794-TBNF AB is a Terminal Base Unit manufactured by Allen Bradley. It has the following parameters:
- Power input: 24V DC
- Number of connections: 16
- Maximum current per connection: 8A
- Backplane current: 6.3A
- Operating temperature range: -25°C to +70°C
- Dimensions: 130mm x 115mm x 90mm
- Weight: 0.3kg
- Wiring type: Spring Clamp
- Certifications: UL Listed, CE Marked, C-Tick Approved
The Terminal Base Unit has the following contents:
- 1794-TBNF AB Terminal Base Unit
- Removable Terminal Block
- End Cover
- Spring Clamp
- Documentation
