1794-OW8 AB
The 1794-OW8 AB is a digital output module from Allen-Bradley, which is designed to operate with the 1794 Flex I/O distributed I/O system.
The module has eight outputs, which can be controlled individually over a network. The module also has a power dissipation of 3.5 watts and a backplane current load of 320 mA.
The 1794-OW8 AB module is designed to operate in a temperature range of -20 to 70 degrees Celsius, and is rated for a shock of 30G and a vibration of 5G. The module is also CE and C-Tick certified, ensuring compliance with European and Australian standards.
In terms of performance parameters, the 1794-OW8 AB module has a maximum switching current of 2 A per channel, with a maximum inrush current of 5 A. The module also has a response time of 8 ms, ensuring quick and accurate control of outputs.
Overall, the 1794-OW8 AB is a reliable and high-performance digital output module, which can be used in a wide range of industrial applications.
Technical Specifications
- Supply Voltage Range: 10…30V DC
- Input Voltage Range: 10…30V DC
- Output Voltage Range: 0…250V AC/DC
- Output Current: 2A per channel
- Operating Temperature Range: -20…60 °C
- Storage Temperature Range: -40…85 °C
- Relative Humidity: 5…95% non-condensing
Features
- Eight digital contact outputs
- Common power supply connection
- Removable terminal block
- LED indicators for status and diagnostics
- Short-circuit and over-current protection
- CE and UL certified
