1794-OB16 AB
The 1794-OB16 AB is a digital output module that provides 16 output channels. It is designed for use with Allen-Bradley programmable controllers. The module has a voltage range of 5-265 V AC/DC.
Each output channel is capable of providing up to 2 A of current. The module has a maximum current rating of 8 A. The output channels are designed to provide high-speed switching for applications requiring fast response times.
The module is designed for easy installation and can be mounted on a DIN rail. It has a compact design and can be easily integrated into existing control systems.
In addition to the standard 1794-OB16 AB module, there is also a 1794-OB16P AB module available. The 1794-OB16P AB module includes diagnostic capabilities, allowing for easy identification of output channel status.
Overall, the 1794-OB16 AB module is a reliable and efficient solution for digital output applications in industrial control systems.
The product information content for the 1794-OB16 AB includes the following:
- Product name and model number
- Description of the module
- Number of output points
- Input voltage range
- Output current rating
- Operating temperature range
- Dimensions and weight
- Wiring diagrams and installation instructions
- Warranty information
Parameters
The following parameters are available for the 1794-OB16 AB:
- Input voltage range: 10-30V DC
- Output current rating: 2A per point, 4A per module
- Operating temperature range: -20°C to +60°C
- Dimensions: 118mm x 87mm x 34mm (4.65in x 3.43in x 1.34in)
- Weight: 200g (7.05oz)
