1794-ASB AB
The AB 1794-ASB is a block I/O module manufactured by Allen-Bradley. It is designed to provide a flexible solution for distributed I/O applications. The ASB module is compatible with ControlLogix and FlexLogix controllers and can be used to interface with various types of analog and digital devices. The module supports up to 32 inputs and 32 outputs and is available in different voltage and current ranges. The AB 1794-ASB module is easy to install, configure, and maintain, making it an ideal choice for industrial automation applications that require reliable and efficient I/O operations.
Features
- Supports up to 8 input and output modules
- Has a maximum data transfer rate of 5 Mbps
- Features a built-in RS-232/422/485 communication port
- Offers diagnostic and status indicators for easy troubleshooting
- Can be configured using the RSLogix 5000 software
Specifications
- Dimensions: 4.13 x 5.07 x 1.60 in. (HxWxD)
- Operating temperature: -25 to 70 °C (-13 to 158 °F)
- Storage temperature: -40 to 85 °C (-40 to 185 °F)
- Input voltage: 10-30V DC
- Power consumption: 5W max
