1784-PCIC AB
The 1784-PCIC AB is designed to provide a high-speed communication interface between a personal computer and Allen-Bradley PLCs. It is compatible with both ISA and PCI bus architectures and supports a wide range of Allen-Bradley communication protocols, including DH+, DH-485, and ControlNet.
The card has two communication channels, each with a maximum baud rate of 115.2 Kbps. It also features an onboard processor and memory, which allows for faster data transfer and reduced load on the computer’s CPU.
In terms of physical specifications, the 1784-PCIC AB measures 6.6 inches in length, 4.2 inches in height, and 0.7 inches in width. It weighs approximately 0.2 pounds and requires a 5V DC power supply.
Overall, the 1784-PCIC AB is a reliable and efficient PC Interface Card that provides seamless communication between a personal computer and Allen-Bradley PLCs.
Specifications
The product offers the following specifications:
- PCI bus compatibility: PCI 2.2
- Power consumption: 5V DC, 800 mA
- Operating temperature: 0 to 60°C (32 to 140°F)
- Storage temperature: -40 to 85°C (-40 to 185°F)
- Humidity: 5 to 95% non-condensing
- Dimensions: 4.2 x 6.9 inches (10.7 x 17.5 cm)
- Weight: 0.2 lb (0.09 kg)
Parameters
The 1784-PCIC AB product supports the following parameters:
- Baud rate: 57.6 kbps, 115.2 kbps, and 230.4 kbps
- Data bits: 7 or 8 bits
- Parity: None, Odd, Even, or Mark
- Stop bits: 1 or 2 bits
- Flow control: Hardware or software
