1771-HSN AB - Changxin Automation

1771-HSN AB

1771-HSN (2)

1771-HSN

1771-HSN AB

The module has the following technical specifications:

Input voltage:24V DC nominal(10-30V DC range)

Power consumption:1.6 W maximum

Operating temperature range:0 to 60 degrees Celsius

Storage temperature range:-40 to 85 degrees Celsius

Relative humidity:5-95%non-condensing

Dimensions(HxWxD):118 x 35 x 87 mm

Weight:160 g

Description

1771-HSN AB

The 1771-HSN AB is a digital input module manufactured by Allen Bradley. It is part of the 1771 I/O system and is designed to operate in industrial environments. The module provides 16 channels of input, each of which can be configured for either sinking or sourcing operation.

The 1771-HSN AB module is designed to operate with a wide range of input voltage levels, from 5V to 265V AC or DC. Each channel is isolated from the others, providing protection against voltage spikes and other electrical noise. The module is also designed to be easy to install and configure, with a simple wiring diagram provided on the front of the module.

Overall, the 1771-HSN AB module is an excellent choice for digital input applications in industrial control systems. Its robust design, flexible configuration options, and ease of use make it a popular choice among engineers and technicians in a variety of industries.

The module has the following technical specifications:

Input voltage: 24V DC nominal (10-30V DC range)
Power consumption: 1.6 W maximum
Operating temperature range: 0 to 60 degrees Celsius
Storage temperature range: -40 to 85 degrees Celsius
Relative humidity: 5-95% non-condensing
Dimensions (HxWxD): 118 x 35 x 87 mm
Weight: 160 g

Parameters

The 1771-HSN AB module has the following user-configurable parameters:

Counting mode: Up, Down, Up/Down
Counting range: 0 to 32,767 pulses
Input filter time: 0 to 65,535 microseconds
Output filter time: 0 to 65,535 microseconds
Counting direction: Positive, Negative, Bidirectional
