1756-PA75 AB

1756-PA75 (5)

1756-PA75 (5)

1756-PA75 AB

The 1756-PA75 AB power supply module has the following parameters:

Input voltage range:85-265 VAC

Input frequency range:47-63 Hz

Inrush current:20 A peak for 10 ms

Input power:200 VA maximum

Efficiency:85%

Overload protection:105-150%of rated output current

Overvoltage protection:30-33 VDC

Undervoltage protection:21-22 VDC

Ripple and noise:150 mVp-p maximum

Description

1756-PA75 AB

Overview

1756-PA75 AB is a power supply module manufactured by Allen-Bradley. It is designed to provide power to the 1756 chassis-based system, which is used in a variety of industrial applications.

Specifications

The following are the specifications of the 1756-PA75 AB power supply module:

Input voltage: 85-265 VAC
Output voltage: 24 VDC
Output current: 7.5 A
Power output: 180 W
Operating temperature: 0-60°C
Storage temperature: -40-85°C
Dimensions (HxWxD): 127x35x145 mm
Weight: 0.68 kg

Parameters

The 1756-PA75 AB power supply module has the following parameters:

Input voltage range: 85-265 VAC
Input frequency range: 47-63 Hz
Inrush current: 20 A peak for 10 ms
Input power: 200 VA maximum
Efficiency: 85%
Overload protection: 105-150% of rated output current
Overvoltage protection: 30-33 VDC
Undervoltage protection: 21-22 VDC
Ripple and noise: 150 mVp-p maximum

Conclusion

The 1756-PA75 AB power supply module is a reliable and efficient component of the 1756 chassis-based system. Its specifications and parameters make it suitable for use in a wide range of industrial applications.
