1756-IT6I AB
Product Content
The 1756-IT6I AB product comes with the following content:
- One 1756-IT6I AB module
- One set of installation instructions
Product Parameters
The 1756-IT6I AB module has the following parameters:
- Temperature range: -40 to 85 degrees Celsius
- Input type: Thermocouple (Types B, E, J, K, R, S, T)
- Number of inputs: 6
- Resolution: 16 bits
- Update rate: 100 ms
The AB 1756-IT6I is a digital input module that is used in a ControlLogix chassis. It provides six isolated inputs that can be used to monitor the state of digital devices such as switches and sensors.
The following are the product parameters for the AB 1756-IT6I:
- Input voltage range: 10 to 30V DC
- Input current range: 4 to 20 mA
- Maximum input voltage: 30V DC
- Isolation voltage: 250V AC/DC
- Isolation group: 3
- Operating temperature range: -20 to 60 degrees Celsius
- Storage temperature range: -40 to 85 degrees Celsius
- Relative humidity: 5 to 95% non-condensing
In addition to the product parameters, the AB 1756-IT6I also has the following features:
- Six isolated inputs
- LED indicators for each input
- Removable terminal blocks for easy installation and maintenance
- Diagnostic information available through the ControlLogix system
Overall, the AB 1756-IT6I is a reliable and versatile digital input module that can be used in a variety of industrial applications.
