1756-IM16 AB
The AB 1756-IM16 is a digital AC input module that belongs to the Allen-Bradley ControlLogix series of programmable logic controllers (PLCs). The module has 16 inputs that are compatible with 100-240V AC voltage levels.
Product Information
- Manufacturer: Allen-Bradley
- Product Series: ControlLogix
- Model Number: 1756-IM16
- Input Type: Digital AC Input
- Number of Inputs: 16
- Input Voltage Range: 100-240V AC
Parameters
- Operating Voltage Range: 85-265V AC
- Input Voltage Range: 79-264V AC
- Input Current @ 120V AC: 8 mA
- Input Current @ 240V AC: 13 mA
- Off-state Voltage Range: 5-30V AC
- On-state Voltage Range: 85-265V AC
- Input Delay Time: 10 ms
- Input Response Time: 8 ms
- Isolation Voltage: 1500V AC
- Isolation Type: Optocoupler
- Weight: 0.3 kg (0.66 lb)
The AB 1756-IM16 module is widely used in industrial automation applications for controlling various processes. Its compact size and high input voltage range make it a suitable choice for many automation systems.
The AB 1756-IM16 is a 16-channel digital input module manufactured by Allen-Bradley. It is designed to be used with the ControlLogix programmable logic controller (PLC) system. The module features 16 individually isolated inputs that can be used to detect the on/off status of various devices within an industrial automation system.
The inputs are compatible with a wide range of devices, including pushbuttons, limit switches, and proximity sensors. The module is capable of detecting both AC and DC signals, with a maximum input voltage of 120V AC or DC. The module also features a built-in LED indicator for each input channel that provides visual status feedback.
The AB 1756-IM16 is designed to operate in harsh industrial environments and is built to withstand extreme temperatures, shock, and vibration. It is also designed to be easily installed and configured, with a plug-and-play design that allows for quick and easy installation without the need for any special tools or training.
Overall, the AB 1756-IM16 is a reliable and versatile digital input module that is ideal for use in a wide range of industrial automation applications.
