1756-IF8 AB
This document provides detailed information about the 1756-IF8 AB product, including its features, specifications, and parameters.
Features
- Eight differential or single-ended inputs
- 16-bit resolution
- Input range: +/-10V, +/-5V, +/-2.5V, +/-1.25V, 0-10V, 0-5V, 0-2.5V, 0-1.25V
- Input filter options: 3dB, 10dB, 100dB
- Supports a wide range of thermocouples, RTDs, and voltage/current inputs
- Provides diagnostics and fault detection
Specifications
- Operating voltage: 10…30V DC
- Power consumption: 3.5W max
- Backplane current load: 550mA at 5V DC, 130mA at 24V DC
- Isolation voltage: 242V continuous, basic insulation type
- Operating temperature: 0…60°C (32…140°F)
- Storage temperature: -40…85°C (-40…185°F)
- Relative humidity: 5…95% (non-condensing)
- Dimensions (HxWxD): 118x35x87mm (4.65×1.38×3.43in)
- Weight: 190g (0.42lb)
Parameters
The 1756-IF8 AB product supports the following parameters:
- Input type (thermocouple, RTD, voltage, current)
- Input range
- Input filter
- Cold junction compensation
- Excitation current (for RTDs)
- High/low alarms
- Scaling
- Linearization
- Diagnostic and fault detection settings
For more information about these parameters, please refer to the product manual.
