1756-CNB AB
This document provides detailed information about the AB 1756-CNB module’s content and parameters.
Description
The AB 1756-CNB is a ControlNet bridge module that provides a secure and high-speed communication link between multiple devices. It allows the connection of up to 99 nodes on a single ControlNet network.
Features
- Supports ControlNet communication
- Supports up to 99 nodes on a single network
- Provides secure communication
- High-speed data transfer
Parameters
The AB 1756-CNB module has the following parameters:
- Bridge Mode: The module can be configured as a bridge or repeater.
- ControlNet Address: The ControlNet address can be set using a rotary switch or through software configuration.
- Baud Rate: The baud rate can be set to 125K, 250K, or 500K.
- Node Address: The node address can be set using a rotary switch or through software configuration.
- Device Type: The device type can be set to a scanner, adapter, or both.
Compatibility
The AB 1756-CNB module is compatible with the following devices:
- ControlLogix 1756-L61, 1756-L62, 1756-L63, 1756-L64, 1756-L65, and 1756-L71 controllers
- FlexLogix 1794-L34, 1794-L35, 1794-L43, 1794-L44, 1794-L53, and 1794-L54 controllers
Conclusion
The AB 1756-CNB module is a reliable and efficient ControlNet bridge module that provides a secure and high-speed communication link between multiple devices. Its compatibility with various devices makes it a versatile module that can be used in various applications.
