1756-A13 AB
Product Description
The 1756-A13 AB is a chassis assembly that supports up to 13 I/O modules. It is compatible with the ControlLogix 1756 series and has a backplane current rating of 10A. The chassis comes with a built-in power supply, which provides power to the I/O modules.
Parameters
The following are the parameters of the 1756-A13 AB:
- Dimensions: 17.32 x 11.68 x 6.26 in. (44.00 x 29.67 x 15.90 cm)
- Weight: 10.1 lb. (4.58 kg)
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Storage Temperature: -40 to 85°C (-40 to 185°F)
- Relative Humidity: 5 to 95% non-condensing
Features
The 1756-A13 AB has the following features:
- Supports up to 13 I/O modules
- Built-in power supply
- Compatible with ControlLogix 1756 series
- Backplane current rating of 10A
The AB 1756-A13 is a digital input/output module manufactured by Allen-Bradley. It is designed to be used with the ControlLogix programmable automation controller (PAC) system. This module has 16 input channels and 16 output channels, which can be used to control and monitor various devices and processes.
The input channels are compatible with both sinking and sourcing devices and have a voltage range of 10 to 30 volts DC. The output channels are capable of driving up to 2 amps per channel at 5 to 125 volts AC or 5 to 50 volts DC.
The AB 1756-A13 is designed to be hot-swappable, which means it can be replaced without having to shut down the entire ControlLogix system. It also has a built-in self-test feature that checks the module’s status and communication with the PAC system.
Overall, the AB 1756-A13 is a reliable and efficient module that provides a high level of flexibility and control in industrial automation applications.
