1747-BSN AB
The 1747-BSN AB is a communication module designed by Allen-Bradley for use with programmable logic controllers (PLCs). This module allows for communication between different devices and networks, making it a valuable tool for industrial automation.
Some of the key features and parameters of the 1747-BSN AB module include:
- Communication protocol: The module uses the DeviceNet protocol for communication with other devices and networks.
- Network topology: The module supports linear, star, and tree topologies, providing flexibility in network design.
- Data transfer rate: The module supports data transfer rates of up to 500 kbps, allowing for fast and efficient communication.
- Input and output: The module has 24V DC input and output voltage ratings, making it compatible with a wide range of devices.
- Operating temperature range: The module can operate in temperatures ranging from 0°C to 60°C, making it suitable for use in a variety of environments.
In addition to these parameters, the 1747-BSN AB module also includes a range of diagnostic and troubleshooting features to help identify and resolve communication issues.
Product Features
The AB 1747-BSN has the following features:
- Supports up to 64 DeviceNet nodes
- Compatible with SLC 500 processors
- LED indicators for power and communication status
- Configurable using RSLogix 500 software
The following parameters can be configured for the AB 1747-BSN module using RSLogix 500 software:
- DeviceNet Baud Rate (125 Kbps, 250 Kbps, or 500 Kbps)
- Explicit Messaging Timeout (0 to 255 ms)
- I/O Messaging Timeout (0 to 255 ms)
- Maximum I/O Data Size (up to 510 bytes)
- Polling Rate (1 to 127 ms)
- Slave Address (1 to 63)
