1746-NO8V AB
The AB 1746-NO8V is a digital output module that is used in conjunction with the Allen-Bradley SLC 500 series programmable logic controllers (PLCs). The module has 8 digital outputs, each capable of sourcing up to 0.5A at 5-125VDC or 5-265VAC.
Product Information
The AB 1746-NO8V module has the following specifications:
- Supply Voltage Range: 5-125VDC or 5-265VAC
- Number of Outputs: 8
- Output Current: 0.5A
- Operating Temperature Range: 0-60°C
- Storage Temperature Range: -40-85°C
- Dimensions (HxWxD): 4.65″ x 3.15″ x 2.36″
Parameters
The following parameters can be configured for the AB 1746-NO8V module:
- Output Type: Determines whether the output is sinking or sourcing.
- Output Polarity: Determines whether the output is active high or active low.
- Output Response Time: Determines the amount of time it takes for the output to turn on or off after it receives a signal from the PLC.
- Output Diagnostic Type: Determines the type of diagnostic information that is available for the output.
- Output Fault Action: Determines what action the module takes when a fault is detected on the output.
It is important to note that the AB 1746-NO8V module must be used with the correct firmware version for the SLC 500 series PLC it will be connected to.
The AB 1746-NO8V is a digital output module manufactured by Allen-Bradley. It is part of the SLC 500 series and is designed to provide a voltage output to control various types of devices such as valves, motors, and other industrial equipment. The module has eight channels, each capable of providing a voltage output between 0 and 10 volts. It can be used with a variety of different load types and has a maximum load current of 25 mA per channel. The AB 1746-NO8V is a reliable and efficient module that is ideal for use in a wide range of industrial applications.
