1746-NO4V AB
The 1746-NO4V AB is a four-channel analog output module manufactured by Allen-Bradley. This module is compatible with various programmable logic controllers (PLCs) and is designed to provide precise analog output signals for a wide range of industrial applications.
Product Information Content
The 1746-NO4V AB module comes with the following product information content:
- Part number: 1746-NO4V AB
- Manufacturer: Allen-Bradley
- Number of channels: 4
- Output range: 0-10V DC or 4-20mA
- Output resolution: 12 bits
- Isolation voltage: 500V AC
- Backplane current: 120mA at 5V DC
- Operating temperature range: 0 to 60°C
- Storage temperature range: -40 to 85°C
- Weight: 0.10 kg
- Dimensions (H x W x D): 118 x 35 x 87 mm
Parameters
The 1746-NO4V AB module has the following parameters:
- Output type: voltage or current
- Output range: 0-10V DC or 4-20mA
- Resolution: 12 bits
- Update time: 5ms
- Output impedance: 0-500 ohms (voltage), 0-500 ohms (current)
- Load resistance: 10k ohms (voltage), 500 ohms (current)
- Accuracy: +/- 0.1% full scale
- Temperature drift: +/- 0.005% full scale per °C
- Output noise: 10mV peak-to-peak (voltage), 25uA peak-to-peak (current)
- Isolation voltage: 500V AC
Overall, the 1746-NO4V AB module is a reliable and high-performance analog output module that is suitable for a wide range of industrial applications.
The AB 1746-NO4V module has the following parameters:
- Operating Voltage Range: 5 to 125 volts DC
- Operating Current Range: 2 amps per output
- Resolution: 16 bits
- Output Type: Digital
- Output Control: PWM or On/Off
- Compatibility: Allen-Bradley SLC 500 series PLCs
- Programming Software: RSLogix 500
- Terminal Block: Removable
