1746-NI16I AB
The 1746-NI16I AB is a module of the Allen-Bradley SLC 500 family. It is a 16-channel analog input module that is used to convert analog signals into digital signals. The module is designed to be used with a wide range of sensors and devices that produce analog signals.
The module has the following key features and parameters:
- 16 differential input channels
- Voltage input range: ±10V DC
- Current input range: 0-20mA
- Input resolution: 16 bits
- Conversion rate: 4ms per channel
- Input impedance: 249 ohms
- Isolation voltage: 250V AC/DC
- Operating temperature: 0°C to 60°C
- Storage temperature: -40°C to 85°C
- Power consumption: 3.5W max at 5V DC
The 1746-NI16I AB module is widely used in industrial automation and control applications. It is commonly used in process control systems, manufacturing systems, and other applications where analog signals need to be converted into digital signals.
The AB 1746-NI16I module has the following key features and specifications:
- 16 single-ended or 8 differential analog input channels
- Supports inputs for voltage, current, and thermocouples
- Resolution of 16 bits
- Input range of +/- 10V, +/- 5V, 0-5V, 0-10V, 4-20mA, and thermocouple types J, K, T, E, R, S, B, and N
- Channel-to-channel isolation
- Overvoltage protection
- LED status indicators
- Removable terminal block
- Operating temperature range of 0-60 degrees Celsius
The AB 1746-NI16I module can be configured using the following parameters:
- Input range
- Filter settings
- Alarm settings
- Scaling and linearization
- Cold junction compensation for thermocouple inputs
- Sampling rate
Overall, the AB 1746-NI16I is a versatile and reliable analog input module that is well-suited for a wide range of industrial applications.
